Xpreshn™

Compact foil/foam laminate: Up to 60% lighter in weight than standard decorative materials, excellent resistance to aging and available in a wide range of colors and grain designs.

Applications

  • Instrument panel
  • Doors/sides/center console
  • Pillar/cover panel/storage areas

Product benefits

  • Up to 60% lighter in weight than standard decorative materials
  • The carbon footprint of Xpreshn™ foam foils is 48% smaller than that of PVC foam foils
  • Excellent resistance to aging
  • Free from halogens and plasticizers
  • Low-emission
  • 100% recyclable
  • Wide range of colors and grain designs
  • Available in a two-color design
  • Flexible during processing

Specifications

  • Construction: Compact foil / foam laminate
  • Thickness: 0.8 mm - 1.4 mm / 2.0 mm - 3.5 mm
  • Backing: None / polyolefin foam
  • Processing method: Vacuum thermo forming, back foaming, low-pressure molding, in-mold graining, thermal welding

Material construction

Foam laminate

1 | Lacquer finish

2 | Compact layer

3 | Foam layer

5 | Backside primer



Compact foil

1 | Lacquer finish

2 | Compact layer

4 | Compact layer

5 | Backside primer
