BR7

BR7

Applications

BR7 is a medium-pressure, twin-line thermoplastic hose with a non-perforated cover. It is compatible with petroleum-, water- and synthetic-based fluids for mobile equipment, lube lines, blowout preventers, hydraulic lifts and construction machinery requiring SAE 100R7 non-conductivity standards.

Specifications

  • Meets or exceeds the performance requirements of:
    • SAE 100R7

Got questions?

Contact us!

Download

    Technical Data Imperial

    SAP Product ID ID OD Max
    Working
    Pressure     		Bend
    Radius     		Min
    Burst
    Pressure    		 Fitting
    Type     		Weight
    (lb/ft)
    Fraction inch inch PSI inch PSI
    20243684 BR7-04 1/4 0.25 0.49 2750 1.30 11000 T7 0.12
    20243685 BR7-05 5/16 0.31 0.58 2500 1.80 10000 T7 0.15
    20243686 BR7-06 3/8 0.38 0.64 2250 2.00 9000 T7 0.19
    20243687 BR7-08 1/2 0.50 0.82 2250 3.00 9000 T7 0.29

    Technical Data Metric

    SAP Product ID ID OD Max
    Working
    Pressure     		Bend
    Radius     		Min
    Burst
    Pressure    		 Fitting
    Type     		Weight
    (lb/ft)
    Fraction mm mm PSI mm PSI
    20243684 BR7-04 1/4 6.40 12.30 19 33.00 75.80 T7 0.12
    20243685 BR7-05 5/16 7.90 14.70 17.2 46.00 68.90 T7 0.15
    20243686 BR7-06 3/8 9.50 16.10 15.5 51.00 62.10 T7 0.19
    20243687 BR7-08 1/2 12.70 20.70 15.5 76.00 62.10 T7 0.29
