AGRIDUR® banded V-belts

For drives with highly irregular load changes and sustained, high power transmission

AGRIDUR® power transmission belts ensure extremely reliable power transmission for agricultural machines thanks to their smooth running properties, even under harsh operating conditions, such as those resulting from dirt, dust and moisture. Furthermore, AGRIDUR® power transmission belts deliver high efficiency, even under the most extreme of weather conditions, such as heat and cold, drought and rain, and direct sunlight. Another factor to bear in mind is that no lubrication is required – a real advantage when compared with chain drives. AGRIDUR® power transmission belts therefore help to significantly reduce maintenance costs.

Belt structure

Belt structure

  • 1. Fabric jacket
  • 2. Body manufactured from fiber-reinforced, heavy-duty synthetic rubber
  • 3. Tension member manufactured from reinforced polyester/aramid
  • 4. Natural rubber backing

AGRIDUR® banded V-belts  can be used within a temperature range of -40°C to +80°C. Their especially smooth running is a particular feature of their operation.

3V (9J) HA
5V (15J) HB
8V (25J) HC
Length range up to 12,500 mm
