CONTI^® FUEL CKR 2162

Fuel hose conductive - stainless steel braided

APPLICATIONS

Diesel fuel pipes

FLOW MEDIUM

Biodiesel resistant, Diesel fuel, Fuel

INNER LINING

FPM/HNBR, black

REINFORCEMENTS

Aramid

COVER

CSM, black, grooved

FURTHER PROPERTIES

Electrically conductive, R < 10⁶ Ω/m, Highly flexible, low permeability

WORKING PRESSURE UP TO

35 bar / 508 psi

TEMPERATURE RANGE

from -40 °C / -40 °F up to +125 °C / +257 °F
up to +150 °C / +302 °F

nominal width	inner-Ø	wall thickness	length	working pressure	min. burst pressure	min. bending radius	weight
zoll/inch	mm	mm	m	bar/psi	bar/psi	aprx. mm	aprx. g/m
1/4	6	3.5	20	25/363	125/1,813	70	233
5/16	8	3.5	20	25/363	125/1,813	80	283
3/8	10	3.5	20	25/363	125/1,813	80	333
1/2	12	3.5	20	25/363	125/1,813	100	369
5/8	15	4.0	20	35/508	175/2,538	110	496

_{Pressure and vacuum based on room temperature / High pressure and/or temperature lead to reduced component durability / Other dimensions upon request}
