TFS Oil Hose


Applications

The high-temperature hose is ideally suited for the secure trans-port of liquid and gaseous media in the high temperature range up to 230°C. Resistant to ozone and UV radiation.


Specifications

  • Black, smooth PTFE inner lining
  • Outer lining with steel wire casing
  • Temperature resistance: -60°C to +230°C
  • High chemical resistance


Technical Data

DN
[mm]
ID
[mm]
OD
[mm]
Operating Pressure
 [bar]
Bursting Pressure
[bar]
Bending Radius
[mm]
Weight
[g/m]
5 4,5 7,6 190 760 40 80
6 6,4 9 170 680 40 100
8 7,9 11 150 600 50 120
10 10 13 140 550 60 150
13 12,5 15,5 105 420 80 210
16 15,3 18,5 95 380 120 270

Pressure information in relation to room temperature. High pressure and/or temperature lead to a reduction in service life. Further dimensions available on request.
