Lactopal®

US_hoses

Marking: Continental ContiTech LACTOPAL® FDA BfR EG 1935/2004 2023/2006 Made in Germany



Applications

Lactopal® is primarily for liquid transfer. Lactopal® is the multi-purpose, high-class hose for the food, pharmaceutical and cosmetic industry. The white lining, resistant to fatty and oily products, is homogeneous, smooth and neutral to taste and odor. It is resistant to commonly used cleaning and disinfecting products. Especially developed for rough working conditions Lactopal® is robust, ensuring dimensional stability and resists running over by trucks. This hose is manufactured to European standards.

Specifications

  • Construction Tube: White, homogenous and non-porous Nitrile lining, absolutely neutral to taste and odor. (FDA Compliant, conforms to 3-A Sanitary Standard 18-03 & meets XXI of BfR recommendations)
  • Cover: Blue Nitrile cover, resistant to ozone, weather, UV and abrasion
  • Reinforcement: Synthetic fibers
  • Temperature Range: -22°F to 176°F (-30°C to 80°C)



Technical Data Imperial

  • Part Number

    InnerØ

    OuterØ

    Weight

    Working
    Pressure

    Bend Radius

    Vacuum HG

    Length

  • (in)

    (in)

    (lbs/ft)

    (PSI)

    (in.)

    (in.)

    (ft)

  • 20836414

    1/2

    0.81

    0.19

    232

    3.13

    17.7

    131

  • 20836415

    5/8

    0.94

    0.22

    232

    3.94

    17.7

    131

  • 20836416

    3/4

    1.13

    0.34

    232

    4.50

    17.7

    131

  • 20836417

    1

    1.44

    0.54

    232

    5.94

    14.7

    131

  • 20836418

    1-1/4

    1.88

    0.94

    232

    7.69

    14.7

    131

  • 20836419

    1-1/2

    2.19

    1.14

    232

    9.06

    14.7

    131

  • 20836420

    1-9/16

    2.25

    1.28

    232

    9.44

    14.7

    131

  • 20836421

    2

    2.75

    1.84

    232

    11.81

    11.8

    100

  • 20836422

    2-3/8

    3.13

    2.02

    232

    16.56

    11.8

    131

  • 20836423

    2-5/8

    3.50

    2.55

    232

    17.94

    11.8

    131

  • 20836424

    2-3/4

    3.69

    2.62

    232

    19.31

    8.8

    131

  • 20836425

    3

    3.88

    2.76

    232

    20.69

    8.8

    100

  • 20836426

    3-1/8

    4.25

    3.43

    232

    22.06

    8.8

    131

  • 20836427

    4

    5.13

    4.50

    232

    27.56

    8.8

    100



Technical Data Metric

  • Part Number

    InnerØ

    OuterØ

    Weight

    Working
    Pressure

    Bend Radius

    Vacuum HG

  • (mm)

    (mm)

    (kg/m)

    (MPa)

    (mm)

    (mm)

  • 20836414

    12.70

    21.00

    0.28

    1.6

    80

    456

  • 20836415

    15.90

    24.00

    0.32

    1.6

    100

    456

  • 20836416

    19.10

    29.00

    0.50

    1.6

    115

    456

  • 20836417

    25.40

    37.00

    0.80

    1.6

    150

    380

  • 20836418

    31.80

    48.00

    1.40

    1.6

    195

    380

  • 20836419

    38.10

    56.00

    1.70

    1.6

    230

    380

  • 20836420

    39.70

    58.00

    1.90

    1.6

    240

    380

  • 20836421

    50.80

    70.00

    2.70

    1.6

    300

    304

  • 20836422

    60.30

    80.00

    3.00

    1.6

    420

    304

  • 20836423

    66.70

    89.00

    3.80

    1.6

    455

    304

  • 20836424

    69.90

    94.00

    3.90

    1.6

    490

    228

  • 20836425

    76.20

    99.00

    4.10

    1.6

    525

    228

  • 20836426

    79.40

    108.00

    5.10

    1.6

    560

    228

  • 20836427

    101.60

    130.00

    6.70

    1.6

    700

    228
