GALAXY® 4867

Application

GALAXY® 4867 GALAXY® 4867
Tube- CR | Barrier- PA | Friction- NBR | Reinforcement- PET | Cover- CIIR


  • 4-Spiral polyester reinforcement
  • Embossed branding for easy identification
  • Extremely flexible under wide temperature range
  • Temperature range -40 °F to 158 °F (-40 °C to 70 °C) per DIN 74310

Dash Size Inside Diameter Outside Diameter Weight
Inch mm Inch mm
Inch mm min. max. min. max. min. max. min. max. lbs/ft kg/m
-14 3/4 19 0.745 0.785 18.9 19.9 1.105 1.145 28.1 29.1 0.26 0.39
