CONTI® FUEL CKR 2150

Fuel hose

CONTI® FUEL CKR 2150
Label: Dimension->ECO< W/J/TC

FLOW MEDIUM

Fuel, Fuel-containing air

INNER LINING

ECO, black

FURTHER PROPERTIES

vent line

WORKING PRESSURE UP TO

1 bar / 15 psi

TEMPERATURE RANGE

from -40 °C / -40 °F up to +125 °C / +257 °F
up to +140 °C / +284 °F

nominal width inner-Ø wall thickness length working pressure min. burst pressure min. bending radius weight
zoll/inch mm mm m bar/psi bar/psi aprx. mm aprx. g/m
1/8 4 2.3 1/15 / 20
1/4 6 2.3 1/15 / 20
1/2 12 2.5 1/15 / 50
Pressure and vacuum based on room temperature / High pressure and/or temperature lead to reduced component durability / Other dimensions upon request
